<p>Make: HAAS</p><p>Model: 93-32-5558B</p><p>Condition: Used, in very good shape. Came from working machine.</p><p></p><p>40 HP Vector Drive/Spindle Inverter</p><p>- Peak Power Rating: 40 HP (approx. 30 kW).</p><p>- Continuous Load: Approx. 22 kW.</p><p>- Input Voltage: 195–260 V AC, 3-phase, 50/60 Hz.</p><p>- Input Current: Up to ~100 A under full load.</p><p>- AC Output (Spindle): 0–200 V AC, PWM controlled.</p><p>- DC Bus Output: 320–340 V DC, supplying all servo amplifiers.</p><p></p><p>Features:</p><ul><li>Combines a 3-phase rectifier, an IGBT power module for spindle control, and a brake chopper unit for overvoltage protection.</li><li>Advanced Cooling: Features a high-performance, thermally-controlled fan that activates at 50°C and is capable of moving up to 230 CFM of air.</li><li>Engineered to handle 150% of the motor's continuous power for up to 15 minutes, and 200% for 3 minutes.</li><li>Facilitates electronic switching between motor windings to provide higher torque at low RPMs and higher speeds at high RPMs.</li><li>Includes integrated status messages and fault reporting for the NGC (Next Generation Control) or Maincon systems.</li></ul>
