CODI Beverage Canning System - Depaletizer, Rinser, Filler, Dryer, Lable Printer

<p><b>DPL-250 DePalletizer Features-</b></p><!--StartFragment--> <ul> <li>Multiple configurations and custom heights available to accommodate your packaging line layout </li> <li>Includes a Single Filer Conveyor with multi-angle transfer plate for connecting to a Twist Rinse, Lowerator, or Vacuum Rinser</li> <li>Carbon steel structure with 3 sided enclosure </li> <li>Superior quality motors and gearboxes with food grade bearings </li> <li>Integrated Chain Lifting System automatically elevates cans to the next layer </li> <li>Side driven sweep arm and locking hardware keeps cans clean during operation </li> <li>Safety locks to keep components from crashing down in the event of a power failure </li> <li>Light curtain safety feature at pallet infeed and on platform </li> <li>PLC with touchscreen HMI </li> <li>Optional remote access from a phone or tablet </li> <li>Three VFDs for speed flexibility </li> <li>Hoist VFD: control rise and decent of pallets </li> <li>Sweep VFD: control pushing of cans onto the single filer </li> <li>Single Filer VFD: control speed of cans feeding into the track</li><li>Pneumatic slip sheet removal</li> </ul><p><b>CCL-45 Counter Pressure&nbsp;Filler&nbsp;Features-</b></p><ul><li>10 Barrels per hour</li><li>137 cases per hour&nbsp;</li><li>55 cans per minute&nbsp;</li><li>309 Gallons per hour</li><li>11.7 Hectolitres per hour&nbsp;</li></ul><!--StartFragment--> <ul><li>Lowest Dissolved Oxygen pickup in the micro canning industry&nbsp;</li><li><!--StartFragment-->Can beverages under a wider range of temperatures and carbonation levels with Counter Pressure technology.<!--EndFragment--></li><li><!--StartFragment--><b>Temperature​:</b> Brewery hose rated for high pressure and temperature(up to 180°F/82°C) with Tri-Clover sanitary fittings.<br> <b>Action/Flow Rate:</b> Cleaning solution is recirculated to achieve high flow rates and conserve resources.<br> <b>Chemicals:</b> 304 stainless steal construction can withstand caustic chemicals.<br> <b>Time:</b> PLC controlled to set the desired cleaning time.</li><li><!--StartFragment-->HMI provides full control over fill rates, pressure, and snift rates.<!--EndFragment--></li><li><!--StartFragment-->Built in buffer tank pressurizes liquid with CO2 prior to filling effectively keeping CO2 in solution.<!--EndFragment--></li><li><!--StartFragment-->Post fill to seam foam management with controlled pressure release.<!--EndFragment--></li><li><!--StartFragment-->CO2 monitoring throughout the fill process</li><li><!--StartFragment-->Audible and visual alerts when the system is compromised.<!--EndFragment--></li><li><!--StartFragment-->Cam driven seaming operations for consistent seals every time.<!--EndFragment--></li><li><!--StartFragment-->Integrated sensors for monitoring stacked lids and lid drop.<!--EndFragment--></li></ul><div><b>​CODI Labeler-</b></div><p></p><ul><!--StartFragment--><li><strong>Inline, Stand-Alone Machine:</strong> Works with all can sizes.<br></li><li> <strong>Accurate Indexing:</strong> Feed screw prevents cans from slipping past labeling point.<br></li><li> <strong>Pressure-Sensitive Labeling:</strong> Ensures consistent label placement.<br></li><li> <strong>Wraparound Labels:</strong> Applied at 25–100 cans per minute (cpm).<br></li><li> <strong>Minimal Changeover:</strong> Thanks to servo motor technology.<b><br><br></b><!--EndFragment--></li></ul><div><!--EndFragment--><b>Conveyors:&nbsp;</b></div><ul><li>Modular Design&nbsp;</li><li>Smooth Can Handling&nbsp;</li><li>Wash down duty cycle capable&nbsp;</li><li>Built to last - 304 stainless steel, food grade belts</li></ul>
