Make: Dymax
Model: 2000 EC Flood
Condition: Used, Overall in Great Shape
Comes With Everything you Will Need, Setup Is Practically New
Manual Shutter
Light Shield
Power Supply
Accessories And Manuals / Prints
The Dymax 2000-EC is a versatile UV light curing flood lamp designed for general-purpose applications, boasting an effective curing area of approximately 8" x 8", making it well-suited for batch processing and large-area cures.
To enhance safety and operational efficiency, users have the option to install a special glass UV filter in the 2000-EC Reflector, reducing UV-B and UV-C spectral emissions. Proper use of the glass UV filter can minimize the need for extensive shielding commonly associated with many lamps.
Featuring convection cooling as a standard, the 2000-EC ensures efficient heat dissipation during operation. For situations requiring additional cooling or vapor removal, an optional fan ventilation kit is available. This kit proves beneficial when lamps are in proximity to heat sources or when eliminating vapors under the lamp/reflector assembly housing during the curing of UV light-curable materials.
Initial Intensity: 105 mW/cm Squared
Curing Area: 8" x 8"
Working Distance: 2" -6"
Reflector Housing Dimensions: 9" x 10.5" x 7.5"
Power Supply Dimensions: 12" x 16" x 4.25"
Power Requirements: 90-265v ,50-60 Hz
