New Bramidan Baler Model X4830
For larger demands
The X4830 is equipped with cross cylinders, giving you stable compression and superior press force, together with a low overall height. Combined with a long stroke, a high bale weight can be achieved.
This baler is designed with easy servicing in mind, for example the positioning of the hydraulic unit mounted below the control panel on the side of the machine. The finished bale can be tied with polyethylene twine or steel wires.
Meets and exceeds ANSI Standards Z245.5 and OSHA Safety Standards. ULå¨ & CULå¨ Approved Control Panel.
Noiseless
Due to an unique hydraulic system
Safe and steady opening of door
Operated by a strong threaded spindle
Easy installation
Very low overall height
Press force (lbs) 66,200
Power supply 208/230/460V 3-phase 60Hz
Motor (HP) 5.5
Noise level (dB) 59-60
Cycle time (sec) 23
Dimensions WxDxH (inch) 69 x 50 x 79
Weight (lbs) 3,150
Feed opening WxH (inch) 43 x 21
Load height (inch) 38
Chamber height (inch) 54
Stroke (inch) 37
Bale size WxDxH (inch) 48 x 30 x 30
Bale weight OCC (lbs) 525-800
Bale weight plastic (lbs) 550-775
