<p>New Bramidan Baler Model X4830</p>
<p>For larger demands</p>
<p>The X4830 is equipped with cross cylinders, giving you stable compression and superior press force, together with a low overall height. Combined with a long stroke, a high bale weight can be achieved.</p>
<p>This baler is designed with easy servicing in mind, for example the positioning of the hydraulic unit mounted below the control panel on the side of the machine. The finished bale can be tied with polyethylene twine or steel wires.</p>
<p>Meets and exceeds ANSI Standards Z245.5 and OSHA Safety Standards. ULå¨ & CULå¨ Approved Control Panel.<br/>Noiseless<br/>Due to an unique hydraulic system<br/>Safe and steady opening of door<br/>Operated by a strong threaded spindle<br/>Easy installation<br/>Very low overall height<br/>Press force (lbs) 66,200<br/>Power supply 208/230/460V 3-phase 60Hz<br/>Motor (HP)&nbsp;&nbsp;&nbsp;&nbsp;5.5<br/>Noise level (dB) 59-60<br/>Cycle time (sec) 23<br/>Dimensions WxDxH (inch) 69 x 50 x 79<br/>Weight (lbs)&nbsp;&nbsp;&nbsp;&nbsp;3,150<br/>Feed opening WxH (inch) 43 x 21<br/>Load height (inch)&nbsp;&nbsp;&nbsp;&nbsp;38<br/>Chamber height (inch) 54<br/>Stroke (inch) 37<br/>Bale size WxDxH (inch) 48 x 30 x 30<br/>Bale weight OCC (lbs) 525-800<br/>Bale weight plastic (lbs) &nbsp;&nbsp;&nbsp;&nbsp;550-775</p><br/><br/><p><br></p>
<table border="0" cellpadding="0" cellspacing="0" class="techTable" width="450">
<tbody>
<tr class="productOdd">
<td>Press force (lbs)</td>
<td>55,200</td>
</tr>
<tr>
<td>Power supply</td>
<td>208/230/460V 3-phase 60Hz</td>
</tr>
<tr class="productOdd">
<td>Motor (HP)</td>
<td>5.5</td>
</tr>
<tr>
<td>Noise level (dB)</td>
<td>59-60</td>
</tr>
<tr class="productOdd">
<td>Cycle time (sec)</td>
<td>23</td>
</tr>
<tr>
<td>Dimensions WxDxH (inch)</td>
<td>69 x 50 x 79</td>
</tr>
<tr class="productOdd">
<td>Weight (lbs)</td>
<td>3,150</td>
</tr>
<tr>
<td>Feed opening WxH (inch)</td>
<td>43 x 21</td>
</tr>
<tr class="productOdd">
<td>Load height (inch)</td>
<td>38</td>
</tr>
<tr>
<td>Chamber height (inch)</td>
<td>54</td>
</tr>
<tr class="productOdd">
<td>Stroke (inch)</td>
<td>37</td>
</tr>
<tr>
<td>Bale size WxDxH (inch)</td>
<td>48 x 30 x 30</td>
</tr>
<tr class="productOdd">
<td>Bale weight OCC (lbs)</td>
<td>500-650</td>
</tr>
<tr>
<td>
<p>Bale weight plastic (lbs)</p>
<p> </p>
</td>
<td>
<p><br></p>
</td>
</tr>
</tbody>
</table>
