4 1/4" CAM SHAFT TOTAL STROKE - MEASURED TO BE 4.25.
AIR CLUTCH AND BRAKE - MINSTER
NEW SIDE SHAFT INCLUDING BUSINGS
NEW PINION GEARS- NEW, TOP AND BOTTOM (ALL 4)
NEW TRANSFER MECHANISM - DOVE TAIL SLIDE AND BRONZE GIBBS
NEW GIBS - FRONT BRONZE CAPS MACHINED AND SCRAPED IN
DRAW 2 1/8" SHELL
NEW TOP SHAFT IN 2001 - ALL NEW PLUNGER CAMS AND LIFT CAMS
11 STRIPPER FORKS
STRIP AND RELEASE SYSTEM
STAGGER FEED - PLUMB PRODUCTS PGY6 DUEL CUT - $5,000 EXTRA
BIJUR PUMP, CHAIN DRIVE TYPE ON BOTTOM SHAFT. OIL LINES TO ALL BEARING AND MOVING SURFACES
220/440V
TYPE: VEHV44-25
SQUARE PLUNGER 15-12
DIMENSIONS: 112" x 55" x 110"
PRESS HAS THE UPDATED SECONDARY CHAIN DRIVEN BACK SHAFT WITH CAMS TO DRIVE THE STRIPPER FORKS DOWN FOR HOLD DOWN PRESSURE AND STRIPPING TIMING
PRESS IS IN EXCELLENT OVERALL CONDITION. HAS BEEN SITTING FOR 5 YEARS OR MORE.
Weight: 18000
