Acer EMC-2550 with ATC Featuring FAGOR Control
Have one to sell?
$74,250.00 USD
ConditionNew
1 available
New
Acer EMC-2550 with ATC Featuring FAGOR Control
FAGOR 8055i/A-MC Control with high speed machining standard.
4 coolant nozzles
Retractable Z axis roller cover
Hard stop limit switch
Three Axes hardened and ground slideway at Rockwell C 45 degrees
FC 30 castings weigh 8,360 lbs
2.5 HP servo motor made in Germany
Automatic arm type tool changer ,
20 tool changer standard
16 or 24 tool changer optional
10 HP spindle motor made in Germany
Electric cabinet is ready for expansion
Overhead control arm has 90 degree swing
EMC spindle contains 5 P4 precision angular contact ball bearings (NSK or FAG)
Table splash guard with retractable doors
Column side guard
Telescopic steel way covers
Y, X axes have square ways
*** Travel without splashguard.
The manufacturer reserves the right to modify the design, specifications, mechanisms, etc. to improve the performances of the machines without notice. All specifications shown above are for reference only.
Weight: 9850
Height: 103
Length: 114
Width: 113
