<p>Acer EMC-3580 93"X 30" Table 13.3Hp 8K Spindle Vert Machining Center W/Fagor 8058i /FL-MC Cntrl</p>
<p>Make: Acer</p>
<p>Model: EMC-3580</p>
<p>Control: Fagor 8055i/FL-MC</p>
<p>Table Size: 92" X 30"</p>
<p>Max Table Load: 3960</p>
<p>Max X-Axis Travel: 78.7"</p>
<p>Max Y-Axis Travel: 33.8"</p>
<p>Max Z-Axis Travel: 22.5"</p>
<p>Spindle Nose To Table: 3.94-29.5"</p>
<p>Spindle Center To Column: 35"</p>
<p>Spindle Taper: Cat 40</p>
<p>Spindle Rpm Ranges: 60-8,000 Rpm</p>
<p>Rapid Traverse Rates: 400 ipm (All Axis)</p>
<p>Cutting Feed Rate: 200 ipm</p>
<p>Positioning: ±0.0005"</p>
<p>Repeatability: ±0.0003"</p>
<p>Max Tool Dia: 3.15"</p>
<p>Max Tool Weight: 15.4"</p>
<p>13.3 Hp Main Spindle Drive</p>
<p>1/4 Hp Coolant Motor<br/>Weighs 17,700 pounds</p>
<p>OPTIONAL ACCESSORIES:</p>
<p>1. 6” Milling Machine…………………………………………………….. $ 450.00</p>
<p>2. “RENISHAW” Tool Touch Probe (TS27R) w/ Software……………... $ P.O.R.</p>
<p>3. “RENISHAW” 3-D Part Probe (OMP40) w/ Software & Holders……. $ P.O.R.</p>
<p>4. 6” Rotary Table w/ Integrated Drive & Motor………………………… $ 10,000.00</p>
<p>5. 8” Rotary Table w/ Integrated Drive & Motor………………………… $ 11,000.00</p>
<p>6. 10 Rotary Table w/ Integrated Drive & Motor………………………… $ 12,000.00</p>
<p>7. Tailstock for Rotary Table (Special Order)……………………………. $ 950.00</p>
<p>8. 8” 3-Jaw Chuck for Rotary Table $ 500.00</p>
<p>9. Upgrade to 440V Transformer…………………………………………. $ 900.00</p>
<p>10. Program Training (Accommodation & Transportation excluded).. Net $ 850/Day/Labor</p>
<p>**For 4th Axis ready, additional Drive & Motor Only…………………. $ 5,500.00</p><br/><br/><p></p>
<h1 style="text-align: center;">Acer EMC-3580 93"X 30" Table 13.3Hp 8K Spindle Vert Machining Center W/Fagor 8055i /FL-MC Cntrl</h1>
<p>Make: Acer</p>
<p>Model: EMC-3580</p>
<p>Control: Fagor 8055i/FL-MC</p>
<p>Table Size: 92" X 30"</p>
<p>Max Table Load: 3960</p>
<p>Max X-Axis Travel: 78.7"</p>
<p>Max Y-Axis Travel: 33.8"</p>
<p>Max Z-Axis Travel: 22.5"</p>
<p>Spindle Nose To Table: 3.94-29.5"</p>
<p>Spindle Center To Column: 35"</p>
<p>Spindle Taper: Cat 40</p>
<p>Spindle Rpm Ranges: 60-8,000 Rpm</p>
<p>Rapid Traverse Rates: 400 ipm (All Axis)</p>
<p>Cutting Feed Rate: 200 ipm</p>
<p>Positioning: ±0.0005"</p>
<p>Repeatability: ±0.0003"</p>
<p>Max Tool Dia: 3.15"</p>
<p>Max Tool Weight: 15.4"</p>
<p>13.3 Hp Main Spindle Drive</p>
<p>1/4 Hp Coolant Motor</p>
<p>OPTIONAL ACCESSORIES:</p>
<p>1. 6” Milling Machine…………………………………………………….. $ 450.00</p>
<p>2. “RENISHAW” Tool Touch Probe (TS27R) w/ Software……………... $ P.O.R.</p>
<p>3. “RENISHAW” 3-D Part Probe (OMP40) w/ Software & Holders……. $ P.O.R.</p>
<p>4. 6” Rotary Table w/ Integrated Drive & Motor………………………… $ 10,000.00</p>
<p>5. 8” Rotary Table w/ Integrated Drive & Motor………………………… $ 11,000.00</p>
<p>6. 10 Rotary Table w/ Integrated Drive & Motor………………………… $ 12,000.00</p>
<p>7. Tailstock for Rotary Table (Special Order)……………………………. $ 950.00</p>
<p>8. 8” 3-Jaw Chuck for Rotary Table $ 500.00</p>
<p>9. Upgrade to 440V Transformer…………………………………………. $ 900.00</p>
<p>10. Program Training (Accommodation & Transportation excluded).. Net $ 850/Day/Labor</p>
<p>**For 4th Axis ready, additional Drive & Motor Only…………………. $ 5,500.00</p>
